EVE-NG 仿真虚拟环境是一种新兴的虚拟无缝仿真平台，可以满足当今 IT 世界的需求。无客户端管理将使 EVE-NG 成为企业工程师的最佳选择，而不受企业安全策略的影响，因为它可以在完全隔离的环境中运行。

镜像制作
#

准备环境
#

说明	类型	描述
eve-ng	企业版、社区版	eve-ng环境
ISO	ISO	镜像文件(Ubuntu、Debian、RockyLinux等)

制作镜像
#

准备环节
#

本次制作以ubuntu 22.04.5为例，对于其他发行版同样适用。

创建目录: 路径/opt/unetlab/addons/qemu

cd /opt/unetlab/addons/qemu

# 创建目录；名字按照eve-ng要求
mkdir linux-ubuntu-22.04.5

上传镜像文件；重命名为cdrom.iso

root@eve-ng:/opt/unetlab/addons/qemu/linux-ubuntu-22.04.5# ls -ltr
total 5601436
-rw-r--r-- 1 root unl  3598123008 Nov  1 13:27 virtioa.qcow2
-rw-r--r-- 1 root root 2136926208 Nov  3 02:56 cdrom.iso

创建virtioa.qcow2文件

qemu-img create -f qcow2 virtioa.qcow2 50G

安装环节
#

浏览器打开eve-ng WEB UI
添加新的实验室

打开新实验室，并添加节点，选择之前创建的目录名字；保存

启动阶段，并双击节点打开console；按照Linux正常引导进行安装
安装完成后，自定义一些配置
1. 开启rootSSH 登录
2. 关闭防火墙
配置完成；关闭节点

转换镜像
#

打开实验室，记住实验ID

转换镜像

一个实验室有多个节点时，请根据需求选择对应的节点ID目录

cd /opt/unetlab/tmp/0/{实验ID}/{节点ID}

转换virtioa.qcow2

qemu-img convert -O qcow2 virtioa.qcow2 virtiob.qcow2

拷贝镜像

# 1. 建议提前删除镜像
rm -rf /opt/unetlab/addons/qemu/linux-ubuntu-22.04.5/virtioa.qcow2

# 2. 拷贝镜像
cp virtiob.qcow2 /opt/unetlab/addons/qemu/linux-ubuntu-22.04.5/virtioa.qcow2

修复权限

/opt/unetlab/wrappers/unl_wrapper -a fixpermissions

删除实验室
创建新实验室，选择镜像；启动节点。愉快的做实验吧

其他类型
#

选择节点时，如果看不到镜像，请在此处复制一个模版/opt/unetlab/html/templates/intel，根据需求修改即可。

iStoreOS
#

创建iStoreOS镜像，本人在此处复制linux模版进行修改。

description
name

root@eve-ng:/opt/unetlab/html/templates/intel# cat istoreos.yml
# Copyright (c) 2016, Andrea Dainese
# Copyright (c) 2018, Alain Degreffe
# All rights reserved.
#
# Redistribution and use in source and binary forms, with or without
# modification, are permitted provided that the following conditions are met:
#     * Redistributions of source code must retain the above copyright
#       notice, this list of conditions and the following disclaimer.
#     * Redistributions in binary form must reproduce the above copyright
#       notice, this list of conditions and the following disclaimer in the
#       documentation and/or other materials provided with the distribution.
#     * Neither the name of the UNetLab Ltd nor  the name of EVE-NG Ltd nor the
#       names of its contributors may be used to endorse or promote products
#       derived from this software without specific prior written permission.
#
# THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT HOLDERS AND CONTRIBUTORS "AS IS" AND
# ANY EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED
# WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE
# DISCLAIMED. IN NO EVENT SHALL <COPYRIGHT HOLDER> BE LIABLE FOR ANY
# DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY, OR CONSEQUENTIAL DAMAGES
# (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;
# LOSS OF USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND
# ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT
# (INCLUDING NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY OUT OF THE USE OF THIS
# SOFTWARE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
---
type: qemu
description: iStoreOS
name: iStoreOS
cpulimit: 1
icon: Server-2D-Linux-S.svg
cpu: 1
ram: 1024
ethernet: 1
console: vnc
shutdown: 1
qemu_arch: x86_64
qemu_version: 2.12.0
qemu_nic: virtio-net-pci
qemu_options: -machine type=pc,accel=kvm -vga std -usbdevice tablet -boot order=cd -cpu host
...
